配置端口隔离01

路由器

<Huawei>sys
[Huawei]interface GigabitEthernet 0/0/0
[Huawei-GigabitEthernet0/0/0]ip address 192.168.0.1 24

交换机

<Huawei>
<Huawei>sys
[Huawei]port-isolate mode ?
  all  All
  l2   L2 only

[Huawei]port-isolate mode l2  #二层隔离
[Huawei]port-group g1         #组名字
[Huawei-port-group-g1]group-member Ethernet 0/0/1 to Ethernet 0/0/2 #隔离范围
[Huawei-port-group-g1]display this
[Huawei-port-group-g1]port-isolate enable group 1

[Huawei]port-group g2
[Huawei-port-group-g2]group-member Ethernet 0/0/3 to Ethernet 0/0/4
[Huawei-port-group-g2]display this
#
port-group g2
 group-member Ethernet0/0/3
 group-member Ethernet0/0/4
#
return
[Huawei-port-group-g2]port-isolate enable group 2
